New Type Industrial Effluent DAF Flotation Machine Water Treatment Machinery-Dissolved Air Floatation for Effluent Treatment

Name: New Type Industrial Effluent DAF Flotation Machine Water Treatment MachineryDissolved Air Floatation for Effluent Treatment
Brand: HuaYU
Price: 1 USD

Wholesale New Type Industrial Effluent DAF Flotation Machine Water Treatment Machinery-Dissolved Air Floatation for Effluent Treatment from china suppliers

video outgoing-inspection : Provided

machinery test report : Provided

core components : PLC, Pump, Pressure vessel, motor

Place of Origin : Hebei, China

Brand Name : HuaYU

warranty : 1 Year

productivity : 3000L/Hour

weight (kg) : 8500

Processing Type : filtration

Dimension(L*W*H) : 3500*1000*1900mm

Power : 5KW, 10KW, 15KW, 30KW

Voltage : 380V, 220V

Contact Now

Product Description

The dissolved air flotation machine is an efficient and stable water treatment equipment that clarifies wastewater by removing oils, greases or other solid suspended matter. Its process design is to dissolve gas into water to the maximum extent under pressure, striving to be in a supersaturated state, and then release air at atmospheric pressure in the flotation tank. The released air forms a large number of tiny bubbles, which adhere to the suspended matter in the water, causing it to float to the water surface with the bubbles, forming scum, which is then removed by a scraping device.

Working principle

Air flotation separation technology refers to dissolving air into water to the maximum extent under a certain working pressure. The next step is to release the pressure-dissolved air water, thereby generating a large number of fine bubbles, which are fully in contact with the oil and suspended flocs in the wastewater, so that they adhere to the microbubbles and float to the water surface with the bubbles to form scum. The scum is scraped off by the scraping system to achieve the effect of purifying water quality.
Heavy particles flow through the inclined plate settling zone,settling to the bottom of the sediment device,and discharged to the sludge tank through the pipeline,then do subsequent processing,and the Clarified purified water will be discharge by the equipment center tube.

New Type Industrial Effluent DAF Flotation Machine Water Treatment Machinery-Dissolved Air Floatation for Effluent Treatment

Product Parameters

Our Advantages

Applications

New Type Industrial Effluent DAF Flotation Machine Water Treatment Machinery-Dissolved Air Floatation for Effluent Treatment Images

Inquiry Cart 0

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	Hebei Huayu Environmental Engineering Co., Ltd.
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Model	Capacity(m²/h)	Size LBH(m)	Operating Weight(T)	Total Power(KW)
HYRQ-5T	3-5	3.5×1×1.9	8.5	5.55
HYRQ-10T	5-10	4.5×1.2×2.1	13.5	5.75
HYRQ-15T	10-15	5×1.5×2.1	17.5	7.8
HYRQ-20T	15-20	5×1.8×2.1	20.5	7.8
HYRQ-30T	20-30	6×2×2.1	27	7.8
HYRQ-40T	30-40	7×2.2×2.1	34	7.8
HYRQ-50T	40-50	7×2.7×2.1	41	10.55
HYRQ-60T	50-60	8×2.8×2.1	48	10.55
HYRQ-70T	60-70	9×3×2.1	58	15.85
HYRQ-80T	70-80	10×3.2×2.1	70	15.85
HYRQ-100T	80-100	10.5×3.6×2.1	80	19.85
HYRQ-150T	120-150	11×3.6×2.5	90	19.85
HYRQ-200T	180-200	12×3.6×2.5	118	28.65
